PA6 GF30 is Nylon 6 reinforced with a nominal 30% glass fiber by weight. It is selected when unfilled PA6 does not provide enough stiffness, creep resistance or dimensional stability. This guide combines a real commercial-grade datasheet, typical cross-supplier property ranges, moisture effects and injection-molding starting conditions.
PA6 GF30 at a Glance
The example values below come from the downloadable PA6 WHG30A datasheet. That PDF does not state specimen conditioning; confirm the method and validate molded parts before design approval.
What Does PA6 GF30 Mean?
- PA6 identifies Polyamide 6, also called Nylon 6.
- GF identifies glass-fiber reinforcement.
- 30 identifies the nominal glass-fiber content by weight.
PA6 GF30 is a material family, not one universal recipe. Heat stabilizers, impact modifiers, lubricants, pigments, flame retardants, resin viscosity and fiber system can all change the final properties and molding behavior. Two materials marked PA6 GF30 are therefore not automatically interchangeable.
PA6 WHG30A Manufacturer Datasheet
The downloadable manufacturer TDS identifies the commercial grade as PA6 WHG30A. The following values are reproduced from that one-page document. They are typical product values, not guaranteed design limits.
| Tài sản | Tiêu chuẩn thử nghiệm | Đơn vị | PA6 WHG30A |
|---|---|---|---|
| Độ bền kéo | ISO 527-2 | MPa | 165 |
| Tensile Strain at Break | ISO 527-2 | % | 9 |
| Cường độ uốn | ISO 527-2 | MPa | 230 |
| Hệ số uốn | ISO 178 | MPa | 6000 |
| Izod Notched Impact Strength | ISO 179 | kJ/m² | 17 |
| Temperature of Deflection Under Load | ISO 75-2/B | °C | 175 |
| Melting Index | ISO 1183 | g/10 min | 20 |
| Độ đặc | ISO 1183 | g/cm³ | 1.36 |
| Molding Shrinkage | ISO 2577 | % | 0.6 |
| Flammability | UL 94 | – | – |
Read the test conditions: ISO 75-2/B is the 0.45 MPa HDT method; it cannot be compared directly with the 1.8 MPa ranges below. The PDF does not state specimen conditioning. Its impact row names Izod but cites ISO 179 (Charpy), its flexural-strength row cites the tensile standard ISO 527-2, and its melting-index row cites ISO 1183 (density); confirm those methods with the supplier before using the figures for approval. The UL 94 result is blank. Request the current signed TDS, batch certificate of analysis and applicable RoHS, REACH or UL documents for the selected grade.
Download PA6 WHG30A Datasheet (PDF)
Need the compound rather than only the data? See the Trang sản phẩm PA6 GF30 for grade selection and send the part requirements with your datasheet or sample request.
PA6 GF30 Typical Property Data
The following tables show illustrative ranges across commercial PA6 GF30 formulations, not additional specifications for WHG30A. Use them only to identify questions for grade selection; values can differ with formulation, specimen thickness, method and conditioning. The WHG30A PDF above is the source for that named grade.
Illustrative PA6 GF30 Mechanical Ranges (Dry as Molded Examples)
| Tài sản | Giá trị (Phạm vi điển hình) | Phương pháp thử nghiệm | Đơn vị |
|---|---|---|---|
| Mô-đun đàn hồi | 9,500-10,500 | ISO 527-1/-2 | MPa |
| Độ bền kéo khi đứt | 170-190 | ISO 527-1/-2 | MPa |
| Độ giãn dài khi đứt | 3.0-4.5 | ISO 527-1/-2 | % |
| Hệ số uốn | 8,000-9,500 | ISO 178 | MPa |
| Cường độ uốn | 260-290 | ISO 178 | MPa |
| Độ bền va đập Charpy (có rãnh) | 12-16 | ISO 179/1eA | kJ/m² |
| Độ bền va đập Charpy (không có rãnh) | 75-95 | ISO 179/1eU | kJ/m² |
| Độ bền va đập Izod (có rãnh) | 11-15 | ISO 180/A | kJ/m² |
| Độ cứng theo phương pháp ấn bi | 200-230 | ISO 2039-1 | MPa |
Tính chất vật lý
| Tài sản | Giá trị (Phạm vi điển hình) | Phương pháp thử nghiệm | Đơn vị |
|---|---|---|---|
| Độ đặc | 1.35-1.38 | ISO 1183 | g/cm³ |
| Khả năng hấp thụ nước (23 °C, trạng thái bão hòa) | 5.5-6.5 | ISO 62 | % |
| Độ hấp thụ nước (23 °C, độ ẩm tương đối cân bằng 50%) | 1.5-2.0 | ISO 62 | % |
| Độ co ngót khi đúc (song song, 1,6 mm) | 0.25-0.40 | ISO 294-4 | % |
| Độ co ngót khi đúc (bình thường, 1,6 mm) | 0.80-1.10 | ISO 294-4 | % |
| Độ co ngót sau khi đúc (song song, 1 giờ ở 110 °C) | 0.05-0.10 | ISO 294-4 | % |
| Post-Molding Shrinkage (normal, 1h at 110 C) | 0.10-0.15 | ISO 294-4 | % |
Tính chất nhiệt
| Tài sản | Giá trị (Phạm vi điển hình) | Phương pháp thử nghiệm | Đơn vị |
|---|---|---|---|
| Nhiệt độ nóng chảy (DSC, 10 K/phút) | 218-222 | ISO 11357-1/-3 | C |
| HDT ở áp suất 0,45 MPa | 215-220 | ISO 75-1/-2 | C |
| HDT ở áp suất 1,8 MPa | 195-210 | ISO 75-1/-2 | C |
| Nhiệt độ làm mềm Vicat (VST/B50) | 205-215 | ISO 306 | C |
| Hệ số giãn nở nhiệt tuyến tính (song song, 23–55 °C) | 2.0-3.0 x 10-5 | ISO 11359-1/-2 | 1/K |
| Hệ số giãn nở nhiệt tuyến tính (trong điều kiện bình thường, 23–55 °C) | 6.0-9.0 x 10-5 | ISO 11359-1/-2 | 1/K |
| Độ dẫn nhiệt | 0.28-0.35 | DIN 52612 | W/(m·K) |
| Nhiệt dung riêng | 1.5-1.7 | — | J/(g·K) |
Tính chất điện
| Tài sản | Giá trị (Phạm vi điển hình) | Phương pháp thử nghiệm | Đơn vị |
|---|---|---|---|
| Hằng số điện môi (1 MHz) | 3.5-4.5 | IEC 60250 | — |
| Hệ số tiêu tán (1 MHz) | 0.01-0.03 | IEC 60250 | — |
| Điện trở thể tích | 1013-1015 | Tiêu chuẩn IEC 60093 | ohm·cm |
| Điện trở suất bề mặt | 1012-1014 | Tiêu chuẩn IEC 60093 | ohm |
| Chỉ số theo dõi so sánh (CTI) | 500-600 | Tiêu chuẩn IEC 60112 | V |
| Độ bền điện môi (1,6 mm) | 30-35 | IEC 60243-1 | kV/mm |
Flammability
| Tài sản | Giá trị | Phương pháp thử nghiệm | Ghi chú |
|---|---|---|---|
| UL 94 Rating (0.8 mm) | HB | UL 94 | Standard GF30 is not flame retardant |
| UL 94 Rating (1.6 mm) | HB | UL 94 | FR V-0 requires specialized FR compound |
| Limiting Oxygen Index (LOI) | 22-24% | ISO 4589 | Burns in normal atmosphere |
| Auto-Ignition Temperature | >400 C | ASTM D1929 | — |
Property Changes with Moisture Conditioning
PA6 absorbs moisture from the environment. At equilibrium with 50% RH at 23 C, a PA6 GF30 part will absorb approximately 1.5-2.0% water by weight. This changes the mechanical properties significantly. Tensile strength decreases by 30-40%, flexural modulus by 25-35%, and impact strength increases by 50-100%. The data table below shows the approximate shift from dry-as-molded to conditioned (50% RH) values:
| Tài sản | Dry (as molded) | Conditioned (50% RH, 23 C) | Thay đổi |
|---|---|---|---|
| Độ bền kéo (MPa) | 180 | 110-130 | -30 to -40% |
| Mô đun uốn (GPa) | 9.0 | 6.0-7.0 | -25 to -35% |
| Charpy Notched Impact (kJ/m2) | 14 | 20-28 | +50 to +100% |
| HDT at 1.8 MPa (C) | 200 | 65-75 (wet) | Significant drop at full saturation |
Các thông số xử lý
Sấy khô
PA6 GF30 must be dried to a moisture content below 0.10% (target 0.05%) before injection molding. Recommended drying: 80 C for 4-6 hours in a desiccant dryer with a dew point of -30 C or lower. Tray drying at 80 C for 8-12 hours is acceptable for non-critical applications but is less reliable than desiccant drying. Do not dry above 90 C — oxidative discoloration (yellowing) begins at higher temperatures.
Ép phun
| Tham số | Recommended Range | Ghi chú |
|---|---|---|
| Melt Temperature (nozzle) | 250-280 C | Lower end for thin walls, upper for thick |
| Nhiệt độ khuôn | 80-100 C | 100 C preferred for crystallinity and surface |
| Tốc độ phun | Từ trung bình đến nhanh | Faster fill reduces fiber orientation variation |
| Hold Pressure | 50-80% of injection pressure | Enough to pack out shrinkage, avoid overpacking |
| Áp suất ngược | 5-15 bar (hydraulic) | Higher back pressure improves melt homogeneity |
| Tốc độ vít | 50-150 rpm | Lower end for larger shot sizes to avoid shear heating |
| Residence Time (max at melt temp) | 10-15 minutes | Purge if longer; degraded PA6 produces burn marks and strength loss |
Mold Design Considerations
- Gate type: All standard gate types are suitable. Pin gates, edge gates, and fan gates all work. Tunnel (submarine) gates require attention to gate diameter — minimum 0.8 mm to avoid excessive shear with 30% GF.
- Vị trí cổng: Position the gate so flow is into the thickest section. Avoid long flow paths that allow the melt front to cool before the cavity fills.
- Xả hơi: Adequate venting is critical. Poor venting leads to burn marks, short shots, and die buildup. Vent depth: 0.01-0.02 mm.
- Góc nghiêng: Minimum 1 degree, 2 degrees preferred for textured surfaces. GF grades shrink tightly onto cores — adequate draft prevents ejection damage.
- Steel selection: 30% glass fiber is abrasive. For production runs exceeding 100,000 shots, use hardened tool steel (min. 52 HRC) for cavities and cores, especially at gates and high-wear areas.
Comparing PA6 GF30 with Related Grades
PA6 GF30 is a common selection, but the following cross-grade values are screening examples, not a matched set of supplier specifications. Compare test method, load and conditioning before using them in a design decision. See the PA6 GF15, PA6 GF30 và PA6 GF40 pages for the available grade routes.
| Tài sản | PA6 không chứa chất độn | PA6 GF15 | PA6 GF30 | PA6 GF50 | PA66 chứa 30% sợi thủy tinh |
|---|---|---|---|---|---|
| Độ bền kéo (MPa) | 80 | 120-140 | 170-190 | 200-230 | 180-200 |
| Mô đun uốn (GPa) | 2.8 | 5.5-6.5 | 8.0-9.5 | 14-16 | 9.0-10.5 |
| Độ bền Izod có khía (kJ/m²) | 5-7 | 7-10 | 11-15 | 13-18 | 10-13 |
| HDT at 1.8 MPa (C) | 65-75 | 180-195 | 195-210 | 210-215 | 240-255 |
| Mật độ (g/cm³) | 1.14 | 1.23 | 1.36 | 1.56 | 1.37 |
| Chi phí tương đối | 1.0x | 1.1x | 1.2x | 1.4x | 1.3x |
PA6 Glass Fiber Grade Comparison: GF15 vs GF30 vs GF40 vs GF50
Glass fiber content drives the performance-cost trade-off in PA6 compounds. The table below shows how increasing glass fiber from 15% to 50% changes key mechanical and thermal properties. Use these screening values to narrow your grade selection before requesting commercial datasheets.
| Tài sản | PA6 không chứa chất độn | PA6 GF15 | PA6 GF30 | PA6 GF40 | PA6 GF50 |
|---|---|---|---|---|---|
| Tensile Strength (MPa, dry) | 70 – 85 | 110 – 130 | 160 – 190 | 180 – 200 | 200 – 220 |
| Độ cứng uốn (MPa) | 2,500 – 3,000 | 4,500 – 5,500 | 8,000 – 10,000 | 10,500 – 12,000 | 13,000 – 15,000 |
| Độ giãn dài khi đứt (%) | 20 – 40 | 3 – 5 | 3 – 5 | 2 – 3 | 1.5 – 2.5 |
| Charpy Notched Impact (kJ/m², 23°C) | 5 – 8 | 8 – 12 | 10 – 15 | 12 – 16 | 13 – 17 |
| Mật độ (g/cm³) | 1.13 – 1.15 | 1.20 – 1.23 | 1.35 – 1.38 | 1.44 – 1.48 | 1.55 – 1.58 |
| HDT/A, 1.8 MPa (°C) | 60 – 75 | 180 – 195 | 200 – 210 | 210 – 215 | 215 – 220 |
| Điểm nóng chảy (°C) | 220 – 225 | 220 – 225 | 220 – 225 | 220 – 225 | 220 – 225 |
| Mold Shrinkage (flow, %) | 1.0 – 1.5 | 0.4 – 0.7 | 0.2 – 0.5 | 0.15 – 0.35 | 0.10 – 0.25 |
| Các ứng dụng điển hình | Non-structural clips, covers | Housings, brackets, medium stiffness | Engine covers, fan shrouds, power tool housings | High-stiffness frames, pump bodies | Metal replacement, extreme rigidity |
Selection guidance: PA6 GF30 is the most commonly specified glass-filled PA6 grade because it delivers the best stiffness-to-cost ratio for typical structural applications. Move to GF40 or GF50 only when the application demands stiffness approaching aluminum or when wall thickness is constrained. Stay with GF15 when flow into thin-wall features or impact toughness at low temperature matters more than maximum rigidity.
PA6 GF30 Commercial Grade Equivalents
| Supplier | PA6 GF30 Grade | Key Features |
|---|---|---|
| BASF | Ultramid B3WG6 / B3EG6 | General-purpose, heat-stabilized, excellent surface finish |
| DuPont | Zytel 73G30 HSL | Heat-stabilized, widely specified in automotive |
| LANXESS | Durethan BKV 30 H2.0 | Heat-aged, good flow for thin-wall parts |
| DSM / Envalior | Akulon K224-G6 | General-purpose, good chemical resistance |
| Domo / Solvay | Technyl C216 V30 | Widely available in Asia, good processability |
| EMS-Grivory | Grilon BG-30 | Good impact balance, suitable for structural parts |
| Radici | Radilon S RV300 | Easy flow, suitable for complex geometries |
| Ensinger | TECAMID 6 GF30 | Stock shapes and machined parts |
When substituting between PA6 GF30 suppliers, compare full datasheets in the same conditioned state (dry-as-molded vs 50% RH), verify mold shrinkage in both flow and transverse directions, and run a production-tool trial. Even nominally equivalent PA6 GF30 grades differ in fiber length retention, color stability, heat aging, and processing window.
Where PA6 GF30 Is Used
PA6 GF30 is commonly considered for structural parts that need higher stiffness and heat resistance than unfilled PA6. The selected commercial grade still has to meet the part’s impact, moisture, chemical, appearance, electrical and flame requirements.
Fan shrouds, structural housings, brackets and selected under-hood components.
Pump bodies, impellers, machine housings and load-bearing supports.
Housings, connectors and supports when the grade meets the required electrical and flammability ratings.
Stiff housings, frames and mechanical components where fiber orientation and surface finish are controlled.
Giới thiệu về dịch vụ cung cấp nhựa kỹ thuật của chúng tôi
As an ISO 9001 certified engineering plastics manufacturer and exporter, we produce PA6 GF30 in heat-stabilized, impact-modified, UV-stabilized and color-matched variants. For the selected formulation, our technical team can provide the matching datasheet, batch-specific certificate of analysis and applicable RoHS, REACH or UL documentation. Send your target properties, annual volume and delivery destination to discuss a standard grade or custom formulation.
Need a PA6 GF30 datasheet for your application or a quotation for supply? Contact our team — specify your volume, delivery destination, and any special requirements (color, certification, impact modification). The current datasheet and quotation scope are confirmed for the selected grade and requirements.
Câu hỏi thường gặp
Is PA6 GF30 one standardized material?
No. PA6 GF30 identifies a PA6 material family with a nominal 30% glass-fiber level. The additive package, resin viscosity, fiber system and conditioning state vary by commercial grade, so compare the complete TDS and validate the molded part.
Is PA6 GF30 the same as PA66 GF30?
No. Both contain nominal 30% glass fiber, but PA6 and PA66 use different base polymers. They differ in melting and heat performance, moisture response, processing window and grade availability.
Is standard PA6 GF30 flame retardant?
Not automatically. A standard grade and a PA6 GF30 FR grade are separate selections. Confirm the exact UL 94 rating, specimen thickness and certification for the chosen commercial grade.
Những đặc tính chính nào cần kiểm tra trong bảng thông số kỹ thuật của PA6-GF30?
Check tensile strength, flexural modulus, the named impact method, HDT test load, density, shrinkage and specimen conditioning. As a named example, WHG30A lists 165 MPa tensile strength (ISO 527-2), 6,000 MPa flexural modulus (ISO 178) and 175°C HDT (ISO 75-2/B, 0.45 MPa). Do not treat the cross-supplier ranges as guarantees for WHG30A.
Tại sao các thông số về độ bền trong bảng dữ liệu kỹ thuật của PA6-GF30 lại khác nhau giữa các nhà cung cấp?
Glass fiber type and length, coupling system, base resin, additives and conditioning can change the result. Compare values measured by the same method and conditioning state; there is no universal percentage allowance that makes two grades equivalent.
Tôi nên hiểu các giá trị trong bảng thông số kỹ thuật của PA6-GF30 như thế nào để áp dụng vào thiết kế của mình?
Choose dry or conditioned data to match the part’s actual service environment, then validate critical dimensions and loads on molded samples. The WHG30A PDF does not state conditioning. Set design margins from the part loads, environment and failure consequences; the datasheet alone does not define a universal safety factor.
Một bảng dữ liệu kỹ thuật PA6-GF30 chất lượng cao cần bao gồm những thông số gia công nào?
Check the selected grade’s drying, melt and mold temperatures, moisture limit and injection settings. The WHG30A one-page PDF provides property data but no processing window; the parameters above are starting points for trials, not guaranteed WHG30A settings.
Technical Review and Data Sources
Technical author and reviewer: WanHan Technical Team
Last Technical Review: September 28, 2026
- WanHan PA6 WHG30A Technical Data Sheet is the source for the named WHG30A values on this page.
- ISO 1183, ISO 527-2, ISO 178, ISO 179, ISO 75-2/B and ISO 2577 are cited as printed in that TDS; noted method inconsistencies must be confirmed before approval.
- Cross-supplier values are reference ranges. Exact properties depend on grade, test method and conditioning; use the current grade TDS and representative testing for qualification.
